Key Setting Operations With the Key Control Block
Chapter 4
K
e
ys
DVS-9000/9000SF
3-704-674-01 (1)
Setting the drop border or shadow parameters
When the [DROP BDR] or [SHDW] button is lit green, the parameter settings
differ between the “key drop OFF” and “key drop ON” modes (see page 42) as
shown below. Switching between these two modes is made by turning the
[KEY DROP] button on or off.
• “Key drop OFF” mode
• “Key drop ON” mode
a) In the “4H mode” and when [Fine Key] (page 214) is on, the setting value range is 0 to 4.
To adjust the edge fill color
When [DROP BDR] or [SHDW] is selected, the [MORE] button lights amber.
Pressing the [MORE] button to turn it green then allows you to adjust the edge
fill color parameters with the knobs.
Setting the outline parameters
When the [OUTLINE] button is lit green, the parameter settings depend on the
key type and whether the separate edge function is active. To activate the
separate edge function, press [Separate Edge], setting it on, in the Edge menu
for the key.
• Separate edge off
Knob Parameter Adjustment Setting values
1 Width Width 0 to 8
2 Position Position 180 to 359
4 Density Density 0 to 100
Knob Parameter Adjustment Setting values
1 Width Width
0 to 8 a)
2 Position Position 0 to 359
4 Density Density 0 to 100
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0 to 100
2 Saturation Saturation 0 to 100
3 Hue Hue 0 to 359
4 Density Density 0 to 100
Knob Parameter Adjustment Setting values
1 Width Outline width
0 to 8
a)
(0 to 100) b)
