Key Setting Operations Using Menus
Chapter 4
K
e
ys
DVS-9000/9000SF
3-704-674-01 (1)
Selecting Key Fill and Key Source
Selecting key fill and key source
To select key fill and key source for key 1 on the M/E-1 bank, use the following
procedure.
1
In the M/E-1>Key1 menu, select HF1 ‘Type.’
The Type menu appears.
2
In the group, select either of the following for use as key fill.
Key Bus: signal selected on the key 1 fill bus
Matte: signal from the dedicated color matte generator
3
If you selected [Key Bus] in step 2 , select the key fill signal on the key row
in the cross-point control block.
To select key fill for key 3 or key 4 in the cross-point control block, press
the key delegation button [KEY3] or [KEY4], turning it on, to allocate the
key row to the key 3 fill bus or key 4 fill bus, then press the desired cross-
point button.
4
If you selected [Matte] in step 2 , in the same Type menu, press the [Matte
Adjust] button to display the Matte Adjust menu, then adjust the single-
color or two-color combination color matte. Select whether to use a single-
color matte or a two-color combination in the group.
Flat Color: Adjust color 1 with the following parameters.
Mix Color: Carry out a color mix. Adjust color 1 and color 2, and select a
mix pattern (see the next section).
5
In the group, specify the key source selection mode.
Self: The key fill bus signal is automatically selected as the key source.
When the key type is selected as chroma key, select [Self].
4 Hue Hue offset amount
−
180.00 to +180.00
Knob Parameter Adjustment Setting values
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 0.00 to 359.99
