Chapter 5
Wipes
C:\WINNT\Profiles\Administrator\Desktop\WORK_08_21\370467401
DVS9000WW\01GB07C05-WW.fm masterpage:Left
246
Basic Procedure for Wipe Settings
DVS-9000/9000SF
3-704-674-01 (1)
If you selected Pattern, you can also carry out the pattern selection by
pressing the [Mix Ptn Select] button in the Matte Adjust menu, to display
the Mix Ptn Select menu. Select any pattern appearing in the Mix Ptn
Select menu (standard wipe patterns 1 to 24) by pressing the appropriate
button, and you can then adjust the following parameters.
5
If you selected Pattern in step 4 , if required, the following modifiers can
be added. After selecting a wipe mix, skip to step 6 .
• When turning [Position] on and setting the pattern position
a) See page 51.
• When turning [Multi] on and using replications of the same pattern
a) See page 53.
• When turning [Aspect] on and setting the aspect ratio of the pattern
a) See page 53.
• When turning [Angle] on in the group and slanting the
pattern
a) See page 51.
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Position H Horizontal position −
200.00 to
+
200.00
a)
2 Position V Vertical position −
200.00 to
+
200.00
a)
Knob Parameter Adjustment Setting values
1 H Multi Number of repetitions of pattern
horizontally 1 to 63
2 V Multi Number of repetitions of pattern
vertically 1 to 63
3 Invert Type Replication layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio −
100.00 to +100.00 a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern rotation − 100.00 to +100.00 a)
