Key Setting Operations Using Menus
DVS-9000/9000SF
3-704-674-01 (1)
Using the subsidiary mask
For example, to use the subsidiary mask for key 1 on the M/E-1 bank, use the
following procedure.
1
In the M/E-1>Key1 menu, select HF4 ‘Sub Mask.’
The Sub Mask menu appears.
2
In the group, select the mask type.
Key Mask: Masks a part of a key.
Bkgd Mask: Masks a part of a background.
3
In the group, select the mask source.
Wipe: wipe pattern selected for a transition
If you select [Wipe], select the pattern and make modifier settings in
the M/E-1> Wipe menu (see page 238), then return to this M/E-
1>Key1 menu.
In the case of a wipe pattern selected for a mask, the modifier [Edge]
and [Direction] settings are not available.
Utility 1 Bus: signal selected on the utility 1 bus
When you selected [Utility 1 Bus], press the key delegation button
[UTIL2], turning it on, in the M/E-1 bank and select the signal in the
key row.
4
Set the mask source parameters.
• When wipe is selected
• When utility 1 bus is selected
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Clip Reference level for creating mask
signal − 7.30 to +109.58
2 Gain Gain
−
100.00 to +100.00
