Chapter 6
DME Wipes
C:\WINNT\Profiles\Administrator\Desktop\WORK_08_21\370467401
DVS9000WW\01GB08C06-WW.fm masterpage:Left
264
DME Wipe Settings for Independent Key Transitions
DVS-9000/9000SF
3-704-674-01 (1)
1
In the group of the Key1 DME Wipe Adjust menu, press
[1ch].
The Pattern Select menu for one-channel mode appears.
2
Select the desired DME wipe pattern group with one of the following
buttons.
Slide Squeeze: slide and squeeze
Split Door: split and door
User Program: user programmable DME
For details of DME wipe patterns, see “Types of DME Wipe Pattern”
(page 57) and the appendix “DME Wipe Pattern List” (Volume 2).
The patterns from the selected pattern group appear on the screen.
3
Press the button to select the desired pattern.
Setting Independent Key Transition DME Wipe
Modifiers
You can set the pattern position for an independent key transition DME wipe.
For an overview of this function, see “Positioner” (page 51).
Setting the DME wipe position (Positioner)
Use the following procedure.
1
In the group of the Key1 DME Wipe Adjust menu, press
[Position], turning it on.
2
Set the following parameters.
To return the DME wipe pattern position to the center of the screen
In the group, press [Center].
Knob Parameter Adjustment Setting values
1 H Horizontal position
−
200.00 to +200.00
2 V Vertical position
−
200.00 to +200.00
