Key Setting Operations Using Menus
Chapter 4
K
e
ys
DVS-9000/9000SF
3-704-674-01 (1)
5
To invert the black/white sense of the mask source, press the [Mask Invert]
button, turning it on.
6
When a pattern is selected as the mask source, set the pattern modifiers as
required.
• When turning [Position] on and setting the pattern position
a) See page 51.
• When turning [Multi] on and replicating the pattern
a) See page 53.
• When turning [Aspect] on and setting the aspect ratio of the pattern
a) See page 53.
• When turning [Angle] on in the group and setting the
angle of the pattern rotation
a) See page 51.
• When turning [Speed] on in the group and setting the
rate of pattern rotation
a) See page 52.
Knob Parameter Adjustment Setting values
1 Position H Horizontal position −
200.00 to +200.00 a)
2 Position V Vertical position −
200.00 to +200.00 a)
Knob Parameter Adjustment Setting values
1 H Multi Number of repetitions of pattern
horizontally 1 to 63
2 V Multi Number of repetitions of pattern
vertically 1 to 63
3 Invert Type Replication layout 1 to 4 a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio −
100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Angle Pattern angle −
100.00 to +100.00 a)
Knob Parameter Adjustment Setting values
1 Speed Rate of pattern rotation − 100.00 to +100.00 a)
