Chapter 5
Wipes
C:\WINNT\Profiles\Administrator\Desktop\WORK_08_21\370467401
DVS9000WW\01GB07C05-WW.fm masterpage:Left
252
Basic Procedure for Wipe Settings
DVS-9000/9000SF
3-704-674-01 (1)
Applying barrel or pincushion distortion to the edge of the wipe
pattern (Spring)
You can set the spring function independently for the main and sub patterns.
Use the following procedure.
1
In the M/E-1 > Wipe menu, select HF5 ‘Main Modify.’
The Main Modify menu appears.
2
Press [Spring], turning it on.
3
Set the following parameters.
a) See page 56.
Applying a spiral effect to the wipe pattern (Spiral)
You can set the spiral function independently for the main and sub patterns.
Use the following procedure.
1
In the M/E-1 > Wipe menu, select HF5 ‘Main Modify.’
The Main Modify menu appears.
2
Press [Spiral], turning it on.
3
Set the following parameters.
a) See page 56.
Possible combinations of wipe patterns and modifiers
Yes: Can be used No: Cannot be used
Knob Parameter Adjustment Setting values
1 Gain Degree of barrel distortion −
100.00 to
+
100.00 a)
Knob Parameter Adjustment Setting values
1 Magnitude Size and direction of the spiral −
100.00 to
+
100.00 a)
2 Wave Speed Speed of the lateral waves −
100.00 to
+
100.00 a)
Modifiers Type of wipe
Standard Enhanced Rotary Mosaic Random/
diamond dust
Direction Yes Yes Yes Yes Yes
