Key Setting Operations Using Menus
DVS-9000/9000SF
3-704-674-01 (1)
2
In the group, set [Color Cancel] on.
3
Adjust the following parameters.
4
Set [Key Active] on.
The chroma key composite image now appears in the monitor.
Key signal adjustments for color cancel
When the color cancel function is set on, you can adjust the key signal for color
cancel.
Use the following procedure.
1
In the group of the Chroma Adjust menu, set [Color
Cancel] on.
2
In the group, set [Cancel Key] on.
The cancel key is now on, and you can now adjust the key signal for color
cancel.
3
Make the following settings, as required, in the group.
• When setting [Key Position] on and adjusting the color cancel key
edge position
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 0.00 to 359.99
5 Filter Filter coefficient 1 to 9
Knob Parameter Adjustment Setting values
1 Clip Color cancel key reference level 0.00 to 100.00
2 Gain Color cancel key gain
−
100.00 to +100.00
Knob Parameter Adjustment Setting values
1 H Phase Move left and right edges of the
color cancel key simultaneously Left edge position
value shown
2 Left Move left edge of the color cancel
key
−
3.00 to +3.00
3 Right Move right edge of the color
cancel key − 3.00 to +3.00
