Chapter 5
Wipes
C:\WINNT\Profiles\Administrator\Desktop\WORK_08_21\370467401
DVS9000WW\01GB07C05-WW.fm masterpage:Left
244
Basic Procedure for Wipe Settings
DVS-9000/9000SF
3-704-674-01 (1)
1
In the M/E-1> Wipe menu, select HF4 ‘Edge/Direction.’
The Edge/Direction menu appears.
2
In the group, select the edge type.
Border: border
Soft: soft edge
Soft Border: soft border
For an overview, see “Edge” (page 50).
3
Set the parameters according to the selection in step 2 .
• When border is selected
• When soft edge is selected
• When soft border is selected
4
When you selected border or soft border, select the edge fill signal in the
group.
Utility 2 Bus: signal selected on the utility 2 bus
Matte: signal from the dedicated color matte generator
5
Depending on the operation in step 4 , carry out the following operation.
When ‘Utility 2 Bus’ is selected: Press Hold Press down Press the key
delegation button [UTIL2], turning it on, and select the signal in the
key row.
When ‘Matte’ is selected: In the same Edge/Direction menu, press [Matte
Adjust] to display the Matte Adjust menu, then adjust the single-color
or two-color combination color matte. Select whether to use a single-
Knob Parameter Adjustment Setting values
1 Width Border width 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Soft Edge softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Width Border width 0.00 to 100.00
2 Inner Soft Border inner softness 0.00 to 100.00
3 Outer Soft Border outer softness 0.00 to 100.00
