Frame Memory Operations
Chapter 7
F
rame Memor
y
DVS-9000/9000SF
3-704-674-01 (1)
2
To preview the combined memory image and input image (the image to be
written to temporary memory) on the monitor screen, in the
group press [Memory Input] to select it.
3
To select the input signal, in the group select the signal.
FMS: Frame memory source bus signal. (For details of the method of
selection see page 266.)
Color: Color matte signal. When this is selected, use the knobs to adjust
the following parameters.
4
As required, set the video processing (see page 269) or masking (see page
270) to be applied to the input signal.
Note
The video processing setting is only valid for frame memory source bus
signal.
5
To select the way in which the memory image and input signal are
combined, press [Composite Adjust].
For details of the setting, see “Selecting the way in which images are
combined” (page 274).
6
In the state in which you want to freeze, in the group press
[Frame].
This writes the combined freeze image to temporary memory.
To return to the previous state immediately after the freeze, press [Undo]
in the group.
To check the video with the freeze released on a monitor
In the group, press [Memory Input].
Saving a processed image
To save a processed image as a file, in the Edit>Composite menu use the
following procedure.
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 0.00 to 359.99
