Frame Memory Operations
Chapter 7
F
rame Memor
y
DVS-9000/9000SF
3-704-674-01 (1)
• When [Ext Key] is selected
4
If you selected [Pattern] as the mask source in step 2 , set the pattern
modifiers as required.
• When turning [Position] on and setting the pattern position
a) See page 51.
• When turning [Multi] on and replicating the pattern
a) See page 53.
• When turning [Aspect] on and setting the aspect ratio of the pattern
a) See page 53.
• When turning [Rotation Angle] on and inclining the pattern
a) See page 51.
Knob Parameter Adjustment Setting values
1 Size Size of pattern 0.00 to 100.00
2 Soft Edge softness of pattern 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Clip Key signal reference level
−
7.30 to +109.58
2 Gain Key sensitivity
−
100.00 to +100.00
Knob Parameter Adjustment Setting values
1 Position H Horizontal position −
100.00 to +100.00
a)
2 Position V Vertical position −
100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 H Multi Number of repetitions of
pattern horizontally 1 to 63
2 V Multi Number of repetitions of
pattern vertically 1 to 63
3 Invert Type Replication layout
1 to 4
a)
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio −
100.00 to +100.00 a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern rotation −
100.00 to +100.00 a)
