Key Setting Operations Using Menus
DVS-9000/9000SF
3-704-674-01 (1)
• Separate edge off
a) In the “4H mode” and when [Fine Key] (page 214) is on, the setting value range is 0.00
to 4.00.
b) When a wipe pattern key or key wipe pattern key is selected as the key type
• Separate edge on
The left, right, top, and bottom border or outline widths can be adjusted
independently. The separate edge function is only valid when a
luminance key, linear key, or chroma key is selected as the key type.
a) In the “4H mode” and when [Fine Key] (page 214) is on, the setting value range is 0.00
to 4.00.
When drop border or shadow is selected: The setting parameter values
depend on the on/off setting of key drop and the selection of 4H mode/
8H mode (see page 42).
• “Key drop OFF” mode
• “Key drop ON” mode
a) In the “4H mode” and when [Fine Key] (page 214) is on, the setting value range is 0.00
to 4.00.
Knob Parameter Adjustment Setting values
1 Width Width 0.00 to 8.00 a)
(0.00 to 100.00)
b)
3 Density Density 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Top Top edge width
0.00 to 8.00
a)
2 Left Left edge width
0.00 to 8.00
a)
3 Right Right edge width 0.00 to 8.00 a)
4 Bottom Bottom edge width 0.00 to 8.00 a)
5 Density Density 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Width Width 0.00 to 8.00
2 Position Position 180.00 to 359.99
3 Density Density 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Width Width 0.00 to 8.00 a)
2 Position Position 0.00 to 359.99
3 Density Density 0.00 to 100.00
