Chapter 5
Wipes
C:\WINNT\Profiles\Administrator\Desktop\WORK_08_21\370467401
DVS9000WW\01GB07C05-WW.fm masterpage:Left
256
Wipe Settings for Independent Key Transitions
DVS-9000/9000SF
3-704-674-01 (1)
1
Press [Position] in the Key1 Wipe Adjust menu, turning it on.
2
Set the following parameters.
a) See page 51.
To move the pattern from its current position to the center through
the course of a transition
Press [Auto Center] in the group, turning it on.
Rotating the wipe pattern (Rotation)
Use the following procedure.
1
In the group of the Key1 Wipe Adjust menu, select the rotation
type.
Angle: Incline the pattern through a fixed angle.
Speed: Rotate at a speed rate.
Magnitude: Rotate the pattern through a fixed angle during the course of
the transition.
2
According to the selection in step 1 , set the following parameters.
• When Angle is selected
a) See page 51.
• When Speed is selected
a) See page 52.
• When Magnitude is selected
Knob Parameter Adjustment Setting values
1 Position H Horizontal position −
200.00 to
+
200.00 a)
2 Position V Vertical position −
200.00 to
+
200.00 a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern rotation −
100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Speed Rotation rate of pattern −
100.00 to +100.00 a)
Knob Parameter Adjustment Setting values
1 Angle Angle of pattern rotation at start of
transition − 100.00 to + 100.00 a)
