Wipe Settings for Independent Key Transitions
Chapter 5
Wipes
DVS-9000/9000SF
3-704-674-01 (1)
a) See page 52.
Setting the wipe pattern aspect ratio (Aspect ratio)
Use the following procedure.
1
Press [Aspect] in the Key1 Wipe Adjust menu, turning it on.
2
Set the following parameter .
a) See page 53.
Replicating the wipe pattern (Multi)
Use the following procedure.
1
Press [Multi] in the Key1 Wipe Adjust menu, turning it on.
2
Set the following parameters.
a) See page 53.
2 Magnitude Angle of rotation through course
of transition −
200.00 to
+
200.00
a)
Knob Parameter Adjustment Setting values
Knob Parameter Adjustment Setting values
1 Aspect Aspect ratio − 100.00 to +100.00 a)
Knob Parameter Adjustment Setting values
1 H Multi Number of repetitions of pattern
horizontally 1 to 63
2 V Multi Number of repetitions of pattern
vertically 1 to 63
3 Invert Type Replication layout
1 to 4
a)
