Basic Procedure for Wipe Settings
Chapter 5
Wipes
DVS-9000/9000SF
3-704-674-01 (1)
color matte or a two-color combination in the group.
Flat Color: Adjust color 1 with the following parameters.
When you select Mix Color for a two-color combination, see the next
paragraph.
Carrying out a color mix for the edge fill matte
When you selected [Matte] for the border or soft border edge fill, you can
combine color 1 and color 2.
For the combination, you can use not only a normal wipe generator pattern, but
also the dedicated color mix pattern.
Use the following procedure.
1
In the group of the Edge/Direction menu , select [Matte], and
press [Matte Adjust].
The Matte Adjust menu appears.
2
In the group, select [Mix Color], turning it on.
3
In the group, make one of the following selections.
Wipe: Use the wipe pattern selected for the transition.
Pattern: Use the dedicated pattern.
4
Depending on the selection in step 3 , set the following parameters.
• When Wipe is selected
• When Pattern is selected
a) The patterns are the same as for a standard wipe. See the appendix “Wipe Pattern List”
(Volume 2).
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 0.00 to 359.99
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
Knob Parameter Adjustment Setting values
1 Size Pattern size 0.00 to 100.00
2 Soft Edge softness 0.00 to 100.00
3 Pattern Pattern number 1 to 24 a)
