Key Setting Operations With the Key Control Block
DVS-9000/9000SF
3-704-674-01 (1)
• When box is selected
When box is selected and the [MORE] button is lit amber, there are more
settings. Press the [MORE] button, so that it changes from amber to green to
make the extra setting.
• When pattern is selected
a) The pattern is the same as a standard wipe. (See the appendix “Wipe Pattern List” (Volume 2).)
Using the subsidiary mask
In the key control block, press the [SUB MASK] button, turning it on. The
parameter settings depend on the mask source selected as [Wipe] or [Utility 1
Bus] in the group of the Sub Mask menu for the key.
• When wipe is selected
• When utility 1 bus is selected
Knob Parameter Adjustment Setting values
1 Top Top position
−
100 (shown as
−
00) to +100
2 Left Left position
−
100 (shown as
−
00) to +100
3 Right Right position − 100 (shown as − 00) to +100
4 Bottom Bottom position
−
100 (shown as
−
00) to +100
Knob Parameter Adjustment Setting values
1 Soft Box softness 0 to 100
Knob Parameter Adjustment Setting values
1 Size Pattern size 0 to 100
2 Soft Edge softness 0 to 100
3 Pattern Pattern number
1 to 24
a)
Knob Parameter Adjustment Setting values
1 Size Pattern size 0 to 100
2 Soft Edge softness 0 to 100
Knob Parameter Adjustment Setting values
1 Clip Reference level for
creating mask signal –7 to +109
2 Gain Gain –100 (shown as
−
00) to +100
