Basic Procedure for Wipe Settings
Chapter 5
Wipes
DVS-9000/9000SF
3-704-674-01 (1)
• When turning [Speed] on in the group and rotating the
pattern at a constant rate
a) See page 52.
6
To adjust color 1, set [Color1] on, and to adjust color 2 set [Color2] on,
then adjust the parameters.
7
To interchange color 1 and color 2, press the [Color Invert] button, turning
it on.
Setting the wipe position (Positioner)
You can set the position independently for the main pattern and sub pattern.
Use the following procedure.
1
In the M/E-1> Wipe menu, select HF5 ‘Main Modify.’
The Main Modify menu appears.
2
In the group, press [Position], turning it on, and set the pattern
position.
a) See page 51.
To return the pattern position to the center of the screen
In the group, press [Center].
To move the pattern from its current position to the center through
the course of a transition
In the group, press [Auto Center], turning it on.
To set the wipe position using the trackball
You can also set the wipe position using the trackball in the device control
block. Use the following procedure.
Knob Parameter Adjustment Setting values
1 Speed Rotation rate of pattern −
100.00 to +100.00
a)
Knob Parameter Adjustment Setting values
1 Luminance Luminance 0.00 to 100.00
2 Saturation Saturation 0.00 to 100.00
3 Hue Hue 0.00 to 359.99
Knob Parameter Adjustment Setting values
1 Position H Horizontal position −
200.00 to +200.00 a)
2 Position V Vertical position −
200.00 to +200.00
a)
