Chapter 10
Misc Men
u
, Etc.
C:\WINNT\Profiles\Administrator\Desktop\WORK_08_21\370467401
DVS9000WW\01GB12C10-WW.fm masterpage:Left
292
Video Process Settings
DVS-9000/9000SF
3-704-674-01 (1)
Video Process Settings
This section describes operations on the M/E-1 and PGM/PST background A
and B buses, and utility buses 1 and 2.
For these operations, use the Misc >Video Process menu in the respective
operating bank.
For video process settings on other buses, see the following.
• Settings for a particular input signal: “Signal input settings” in Chapter
16 (Volume 2)
• Key fill bus settings: “Video Processing” (page 223)
• Settings for frame memory source buses 1 and 2: “Setting video
processing” (page 269)
• Settings for Aux buses: “Making video process settings for an AUX bus”
(page 291)
• Overview of video process: “Video Process” (page 69)
This section describes an example on the background A bus of the M/E-1 bank.
For the background B bus or utility bus 1 or 2, make the adjustment with a
similar procedure.
Making video process settings for each bus
Use the following procedure.
1
In the menu control block, press the top menu selection button [M/E1] and
select VF7 ‘Misc’ and HF2 ‘Video Process.’
2
In the group, press [Video Process], turning it on.
3
Adjust the following parameters.
To return the parameter settings to the defaults
Press [Unity] in the group.
Knob Parameter Adjustment Setting values
1 Video Gain Video signal gain
−
200.00 to +200.00
2 Y Gain Luminance signal gain
−
200.00 to +200.00
3 C Gain Chrominance signal gain
−
200.00 to +200.00
4 Hue Delay Hue delay − 180.00 to +180.00
5 Black Level Black level
−
7.30 to +109.58
