Key Setting Operations Using Menus
DVS-9000/9000SF
3-704-674-01 (1)
7
To make the edge soft, press [Soft Edge] to set it on, and adjust the
softness.
• For a normal edge, when [Soft Edge] is enabled, “key drop ON mode”
(see page 42) turns on.
• When a luminance key or linear key is selected as the key type, and clean
mode is enabled, enabling [Soft Edge] turns the clean mode off.
8
To make separate fine adjustments to the positions of the left, right, top,
and bottom of the source edge, press [Fine Key], to set it on, and adjust the
following parameters.
Note
In the emboss function it is not possible to set [Fine Key] on.
• When the edge type is normal, drop border or shadow, enabling the [Fine
Key] function fixes the key in the “Key drop ON” mode (see page 42).
• When applying a border to the key edge, enabling the [Fine Key]
function halves the border width setting range.
Carrying out a color mix for the key edge fill matte
When you select ‘Matte’ for the edge fill of a border, drop border, or shadow,
you can create a combination of color 1 and color 2 using a wipe pattern
generated by the dedicated pattern generator.
Use the following procedure.
Knob
Parameter
Adjustment
Setting values
1
Luminance
Luminance
0.00 to 100.00
2
Saturation
Saturation
0.00 to 100.00
3
Hue
Hue
0.00 to 359.99
Knob
Parameter
Adjustment
Setting values
1
Soft
Edge softness
0.00 to 100.00
Knob
Parameter
Adjustment
Setting values
1
Top
Key top edge position
−
2.00 to +2.00
2
Left
Key left edge position
−
2.00 to +2.00
3
Right
Key right edge position
−
2.00 to +2.00
4
Bottom
Key bottom edge position
−
2.00 to +2.00
6
H Phase
Key horizontal position
Left edge position
value shown
7
V Phase
Key vertical position
Top edge position
value shown
