Values for x-, y- and z-axes (16:9 mode)
Limits of three-dimensional parameters
The following table shows the limits of three-dimensional transformation
parameters.
The three-dimensional parameters of an image change when you use the
trackball or Z-ring to execute a transformation. You can also execute a
transformation by entering parameter values from the numeric keypad control
block.
Detents
The system defines points called detents at regular intervals on the three-
dimensional space. Pressing the [CTR] button in the device control block sets
the current three-dimensional parameter values to the closest detent points.
(For details, see “Three-Dimensional Transformation Operations” in Chapter
11 (Volume 2).)
The following table shows the interval between successive detents for each
transformation operation mode (see page 76).
Operation mode Limits of three-dimensional transformation parameters
Location XYZ
−
333.3333 to +333.3333
Rotation, Spin
−
999.9999 to +999.9999
Axis Location
−
333.3333 to +333.3333
Location Size 0.0000 to +999.9999
Aspect 0.0000 to +2.0000
Perspective Perspective (x, y)
− 33.3333 to +33.3333
Perspective (z)
0.0000 to 999.9999
Skew
−
3.3333 to +3.3333
Operation mode Detent interval
Location XYZ 1.00
Rotation, Spin 0.25
Axis Location 1.00
Location Size 0.25
Aspect 1.00 a)
Perspective (x, y)
Perspective (z) 1.00
1.00 a)
Skew 0.10
