STB NIP 2212 Web Server
82 890USE17700 April 2004
Configuring a Role Name
Introduction You can assign, edit, or delete a role name for an STB NIP 2212 on the Role Name
web page. A role name comprises the STBNIP2212 part number, an underscore (_),
and three numeric characters, e.g., STBNIP2212_002.
A role name is the priority IP address assignment method used by the
STB NIP 2212 (See The IP Address Assignment Process, p. 63). If a role name is
assigned, the IP address for the STB NIP 2212 is always associated with it. You will
not be able to assign a configured IP (See Customer-Configured IP Address, p. 62)
or the default IP address (See Deriving an IP Address from a Media Access Control
(MAC) Address, p. 61), unless you remove the role name first.
Sample
Role Name Web
Page A sample Role Name web page is shown below:
