STB NIP 2212 Web Server
78 890USE17700 April 2004
Setting Up
Master
Controllers for
the Island Use the following procedure to configure a master controller for the STB NIP 2212:
Sample Master
Controller Web
Page A sample Master Controller web page is shown in the following figure:
Step Action
1 Click on the Configuration tab to display the Configuration menu.
2 Select the Master Controller option.
3 Type the IP address for each master controller (up to three) that you want to set
up.
4 Type a value for the reservation time (0 ... 120000 ms). This is the amount of
time allocated to any master controller. The default setting is 60000 ms (1 min).
5 Type a value in ms for the holdup time. The default setting is 1000 ms. (1 sec).
The valid values are:
z values in the range 300 ... 120,000 ms.
z a value of 0 ms signifiying indefinite hold up time
Note: You must enter the holdup value via the web page.
6 Click on the Save button to store information about the master controller in the
STB NIP 2212’s Flash memory and in RAM.
