The STB NIP 2212 NIM
42 890USE17700 April 2004
Module Specifications
Specifications
Detail The general specifications for the STB NIP 2212, which is the Ethernet network
interface module (NIM) for an Advantys STB island bus, appear in the following
table:
General Specifications
dimensions
width 40.5 mm (1.594 in)
height 130 mm (4.941 in)
depth 70 mm (2.756 in)
interface and
connectors to the Ethernet LAN RJ-45 female connector
CAT5 STP/UTP twisted-pair, electrical
cable(s)
RS-232 (See Physical
Description, p. 33) port for device
running the Advantys
configuration software or an HMI
panel (See The HMI Blocks in the
Island Data Image, p. 170) eight-pin connector HE-13
to the external 24 VDC power
supply two-pin connector (See The Power
Supply Interface, p. 35)
built-in power
supply input voltage 24 VDC nominal
input power range 19.2 ... 30 VDC
internal current supply 400 mA@ 24 VDC, consumptive
output voltage to the island bus 5 VDC nominal
2% variation due to temperature drift,
intolerance, or line regulation
1% load regulation
< 50 mΩ output impedance up to
100 kHz
output current rating 1.2 A @ 5 VDC
isolation no internal isolation
Isolation must be provided by an
external 24 VDC source power supply,
which must be SELV-rated.
addressable
modules
supported per segment 16 maximum
per island 32 maximum
