Glossary
186 890USE17700 April 2004
size 2 base A mounting device, designed to seat an STB module, hang it on a DIN rail, and
connect it to the island bus. It is 18.4 mm wide and 128.25 mm high.
size 3 base A mounting device, designed to seat an STB module, hang it on a DIN rail, and
connect it to the island bus. It is 28.1 mm wide and 128.25 mm high.
slice I/O An I/O module design that combines a small number of channels (usually between
two and six) in a small package. The idea is to allow a system developer to purchase
just the right amount of I/O and to be able to distribute it around the machine in an
efficient, mechatronics way.
SM_MPS state management_message periodic services. The applications and network
management services used for process control, data exchange, error reporting, and
device status notification on a Fipio network.
SNMP simple network management protocol. The UDP/IP standard protocol used to
manage nodes on an IP network.
snubber A circuit generally used to suppress inductive loads—it consists of a resistor in
series with a capacitor (in the case of an RC snubber) and/or a metal-oxide varistor
placed across the AC load.
source load A load with a current directed into its input; must be driven by a current source.
standard I/O Any of a subset of Advantys STB input/output modules designed at a moderate cost
to operate with user-configurable parameters. A standard I/O module may be
reconfigured with the Advantys configuration software and, in most cases, may be
used in reflex actions.
standard
network
interface An Advantys STB network interface module designed at moderate cost to support
the configuration capabilities, multi-segment design and throughput capacity
suitable for most standard applications on the island bus. An island run by a
standard NIM can support up to 32 addressable Advantys STB and/or preferred I/O
modules, up to six of which may be standard CANopen devices.
standard power
distribution
module An Advantys STB module that distributes sensor power to the input modules and
actuator power to the output modules over two separate power buses on the island.
The bus provides a maximum of 4 A to the input modules and 8 A to the output
modules. A standard PDM requires a 5 A fuse to protect the input modules and an
8 A fuse to protect the outputs.
