IP Parameters
62 890USE17700 April 2004
MAC-Based
IP Address
Example In the following example, the hex pairs in the example IEEE global address
(MAC address) 54.10.2D.11 are converted into a decimal number in the derived
IP address. The derived IP address is 84.16.45.17, so this becomes the default
IP address for the example STB NIP 2212:
Server-Assigned
IP Addresses A server-assigned IP address may be obtained from either a BootP or a DHCP
server. A BootP server must be invoked using either BOOTP position on the lower
rotary switch (See Physical Description, p. 28). A DHCP-served IP address is
associated with a role name.
Role Name A role name is a combination of the Ethernet NIM part number STBNIP2212 and a
numeric value, e.g., STBNIP2212_123.
A role name may be assigned in one of two ways:
z using the numeric settings (00 to 159) on the rotary switches (See Physical
Description, p. 28)
z
setting the lower rotary switch to an INTERNAL position, powering on the
STB NIP 2212, and completing the Role Name web page (See Sample
Role Name Web Page, p. 82).
Customer-
Configured
IP Address If your STB NIP 2212 does not have a role name, you can configure an IP address
directly on the Configured IP web page (See Sample Configured IP Web Page,
p. 72). Set the lower rotary switch to an INTERNAL position, power on the
STB NIP 2212, and complete the web page.
Hex Pair Decimal Conversion
5 x 16 = 80 + 4= 84
10
1 x 16 = 16 + 0 = 16
2D
2 x 16 = 32 + 13 = 45
D = 13 in hex
11
1 x 16 = 16 + 1 = 17
