STB NIP 2212 Web Server
68
890USE17700 April 2004
Accessing the
STB NIP 2212
Web Site
Use the following steps to access the STB NIP 2212 web site:
Product Support
Web Page
Information about how to contact Schneider Electric about your STB NIP 2212
product is available from the Support web page. A sample Support page appears in
the following figure:
Step
Action
Result
1 Go to your url: http://configured IP address
The STB NIP 2212
home page is displayed.
2 Enter your language preference. English is the default
language.
z
If your language preference is English, click on the
Enter button.
z
To select a different language, click on its name, e.g.,
Deutsche. Then click on the Enter button.
The web access
password dialog box is
displayed.
3 Type the user name and the web access password for
your STB NIP 2212 site. Then click on the OK button to
proceed.
Note: The default user name and password are USER.
Both are case-sensitive. They should be changed (See
Web Access Password Protection, p. 86) for your
STB NIP 2212 web site.
The STB NIP 2212
Properties (See
Properties Web Page,
p. 69) page is displayed.
4 To navigate to a different web page, click on its tab. For
example, for information about how to contact the
STB NIP 2212 product support team, click on the Support
tab.
The Support web page
(See Product Support
Web Page, p. 68) is
displayed.
