STB NIP 2212 Web Server
890USE17700 April 2004 71
Configuration Web Page
Introduction The web-based resources that are available for configuring the STB NIP 2212 are
listed as options on the Configuration menu. The specific web page for each feature
is linked to a menu option.
Web-Based
Configuration
Options The Configuration menu appears in the following figure:
Accessing the
Configuration
Menu Use step 1 in the following procedure to access the Configuration menu. Then use
step 2 to navigate to the specific web page for the configuration option:
Step Action Result
1 Click on the Configuration tab. The Configuration menu is displayed.
2 Click on the option that you want to use,
e.g., Master Configurator (See Master
Configurator Web Page, p. 79). The web page for the configuration
option that you selected is displayed.
