STB NIP 2212 Web Server
890USE17700 April 2004 109
Transparent Factory Ethernet (TFE) MIB Subtree
Introduction The Transparent Factory Ethernet (TFE) private is a subtree of the
Groupe_Schneider private MIB. The TFE SNMP component controls
Groupe_Schneider’s private MIB function. Via its associated network
communications services, the Groupe_Schneider private MIB manages and
monitors all of the Advantys STB system components.
The TFE MIB provides data to manage the main TFE communications services for
the communication components that are part of the TFE architecture. The TFE MIB
does not define specific management applications and policies.
Transparent
Factory Ethernet
(TFE) MIB
Subtree The Transparent_Factory_Ethernet(1) defines groups that support TFE services
and devices:
Service Description
Port 502_Messaging(2) subtree that defines objects for managing explicit client/server
communications
web(5) subtree that defines objects for managing embedded web
server activity
equipment_profiles(7) subtree that identifies objects for each type of device in the TFE
product portfolio
Note: Numbers such as 1, 2, 5, and 7 are OIDs.
