STB NIP 2212 Web Server
890USE17700 April 2004 75
Restoring
Default
Parameters from
the Web Use the following procedure to reconfigure the STB NIP 2212 with its default
IP parameters (See Deriving an IP Address from a Media Access Control (MAC)
Address, p. 61) from the web. Note: Your STB NIP 2212 cannot have a role name.
Step Action Comment
1 Open the STB NIP 2212 web site.
2 Click on the Configuration tab to display
the Configuration menu.
3 Select the Configured IP option. The Configured IP web page (See Sample
Configured IP Web Page, p. 72) opens.
4 Click on the Default button. The IP address parameters are restored
to their default values.
The address is based on the 48-bit MAC
address that was programmed into the
STB NIP 2212 when it was manufactured.
5 Click on the Save button to save the
address to Flash memory and in RAM. Note: The LAN ST LED (See Ethernet
Communications LEDs, p. 31) on the NIM
blinks six times if the STB NIP 2212
default address is in use. If the address is
a duplicate, the LAN ST LED blinks four
times.
6 Click on the Configuration tab to return
to the Configuration menu.
7 Select the Reboot option (See About the
Reboot Option, p. 76).
8 At the Reboot now? prompt, click on the
OK button.
9 Click on the OK button at the
confirmation prompt, "Are you sure?"
