Data Exchange
890USE17700 April 2004 127
11 Serious configuration mismatch—the island bus has been set to pre-operational mode,
and initialization is aborted.
12 The configuration matches, and the island bus is operational.
13 The island is operational with a configuration mismatch. At least one standard module
does not match, but all the mandatory modules are present and operating.
14 Serious configuration mismatch—the island bus was started but is now in pre-operational
mode because of one or more mismatched mandatory module(s).
15 The island has been set to pre-operational mode, for example, by the stop function.
16 A value of 1 in bit 8 is a fatal error. It indicates a low-priority receive queue software overrun
error.
17 A value of 1 in bit 9 is a fatal error. It indicates a NIM overrun error.
18 A value of 1 in bit 10 indicates an island bus-off error.
19 A value of 1 in bit 11 is a fatal error. It indicates that the error counter in the NIM has
reached the warning level and the error status bit has been set.
20 A value of 1 in bit 12 indicates that the NIM’s error status bit has been reset.
21 A value of 1 in bit 13 is a fatal error. It indicates a low-priority transfer queue software
overrun error.
22 A value of 1 in bit 14 is a fatal error. It indicates a high-priority receive queue software
overrun error.
23 A value of 1 in bit 15 is a fatal error. It indicates a high-priority transfer queue software
overrun error.
