STB NIP 2212 Web Server
112
890USE17700 April 2004
Equipment Profiles Subtree
Introduction
The Equipment_Profiles subtree (OID 7) identifies objects for every device type in
the TFE product portfolio.
Equipment
Profiles MIB
Subtree
The following table describes the objects contained in the Equipment Profiles MIB
subtree (group) that are common to all TFE products:
Service
Description
Comment
profile Product Name(1)
displays the commercial
name of the
communication product
as a string
e.g., STB NIP 2212
profileVersion(2)
displays software version
of STB NIP 2212
e.g., Vx.y or V1.1
profileCommunicationServices (3) displays list of
communication services
supported by the profile
e.g., Port502Messging, Web
profileGlobalStatus(4)
indicates global_status of
the STB NIP 2212
available values
z
1–nok
z
2–ok
profileConfigMode(5)
indicates the IP
configuration mode of the
STB NIP 2212
available values
z
1–local: the IP
configuration is created
locally
z
2–DHCP-served: the IP
configuration is created
remotely by a DHCP
server
profileRoleName(6)
indicates role name for
IP address management
if none, value is no role
name
profileBandwidthMgt(7)
indicates the status of
bandwidth management
value is always disabled
profileBandwidthDistTable(8)
not available
profileLEDDisplayTable(9)
displays a table giving the
name and state of each
module’s LEDs
refer to the STB NIP 2212
LEDs discussion (See LED
Indicators, p. 30)
