STB NIP 2212 Web Server

890USE17700 April 2004

111

Web MIB Subtree

Introduction

The Web MIB subtree, OID 5, defines objects for managing embedded web server
activity.

Web MIB Subtree

The following table describes the objects in the Web subtree that support Ethernet
services used by the Advantys STB system:

Service

Indication

Available Values

webStatus(1)

global status of the web service

1–idle
2–operational

webPassword(2)

switch to enable/disable use of web
passwords

1–disabled (see table
note)
2–enabled

webSuccessfulAccess(3)

total number of successful accesses
to the STB NIP 2212 web site

webFailedAttempts(4)

total number of unsuccessful
attempts to access the
STB NIP 2212 web site

Note: Disabling the webPassword service will disable the default HTTP password (See
Default User Name and Password, p. 86) for the STB NIP 2212 embedded web server.
