Global Positioning System (GPS)
Rev 3.0B Feb.08 90
RAP Reports Over-The-Air (Remote)
To configure your PinPoint‐E to send RAP reports to a remote
AVL host server, you will need to set 3 commands: *PPIP,
*PPPORT, and *PPGPSR.
a. Set the IP address of the host with *PPIP and desired
port on the host with *PPPORT.
Figure 9-14: AceManager : PinPoint - *PPIP, *PPPORT
b. Set the GPS Report Type, using *PPGPSR, to your
preferred RAP report type.
11 ‐ GPS ‐ Global Positioning System data
12 ‐ GPS + Date ‐ GPS data with the UTC time and
date
13 ‐ GPS + Date + RF ‐ GPS data with the UTC time
and date and Radio Frequency information from the
antenna.
Figure 9-15: AceManager : PinPoint - *PPGPSR
Tip: If your AVL host server uses a dynamic IP address or needs to
change its IP address for any reason, you can use the RAP configu-
ration command to change the value for *PPIP.
RAP Reports over a Local Connection
Local reports are sent to the local IP address of the computer or
device connected directly to a port on the PinPoint‐E. The
reports are sent using PPP or SLIP for serial. To configure the
modem to send reports to the local IP address, you will need to
set 3 commands: S53 in the Misc group and *PPLATS and
*PPLATSR in the PinPoint group.
a. Set the S53 port to the local port to which you want the
reports sent. The local IP address will automatically be
used.
