IBM RS/6000 - Manual (Page 49)

Table 5. Supported Monitors on Model E20
Description Model Feature
Code
Screen
Size
P50 UV-N MPR-II Color Monitor 6553-503 3612 13.6"
P50 UV-S MPR-II Color Monitor 6553-504 - 13.6"
P50 TCO-92 Color Monitor 6553-523 - 13.6"
P70 Color Monitor 6554-603 3613 15.9"
P70 UV-S MPR-II Color Monitor 6554-604 - 15.9"
P200 Color Monitor 6555-703 3614 19.1"
P200 UV-S MPR-II Color Monitor 6555-704 - 19.1"
P201 Color Monitor 6555-803 3615 19.1"
IBM 14V Color Monitor 6324/001 - 13.0"
IBM 15V Color Monitor 6325/001 - 13.7"
IBM 17V Color Monitor 6327/001 - 15.8"
IBM 21P Color Monitor 9521/001 - 19.1"
IBM 14P Color Monitor 9524/001 - 13.0"
IBM 15P Color Monitor 9525/001 - 13.7"
IBM 17P Color Monitor 9527/001 - 15.4"
G40 Monitor 6542-G40 - 13"
G41 Monitor 6542-G41 - 13"
G50 Monitor 6543-G41 - 13.6"
G70 Monitor 6544-G50 - 15.9"
G200 Monitor 6545-G20 - 19.1"
Note: Maximum graphics adapters: 1
2.4.2.5 PCI SCSI-2 Adapters
The following two PCI SCSI adapters are supported:
PCI SCSI-2 Single Ended Fast/Wide Adapter (feature #2408)
PCI SCSI-2 Differential Fast/Wide Adapter (feature #2409)
PCI SCSI-2 Single Ended Fast/Wide Adapter
The adapter can burst data to devices on the SCSI bus at 20 MB/sec.
It has both an internal and an external connector which are physically connected to
the same SCSI bus. The adapter external connector is a shielded 68-conductor
connector consisting of two rows of 34 female contacts.
The adapter supports both 8-bit and 16-bit devices.
The maximum number of addressable IDs enabled by the adapter is 15, but due to
cabling restrictions, the actual total number of supported devices attached to the
internal and external connector may be less.
The adapter occupies one PCI bus slot, and a maximum of six adapters can be
installed in the RS/6000 Model E20.
Chapter 2. PCI-Based RS/6000 Server Hardware 25
