12. From the menu described in Figure 39 on page 124, select the correct
Interrupt Level, Bus I/O Address and Bus Memory values, and press Enter.
Add a X.25 Coprocessor/1 Adapter
Type or select values in entry fields.
Press Enter AFTER making all desired changes.
[Fields]
Description X.25 Coprocessor/1 Adapter
Parent Device bus1
ISA Interrupt Level [11]
Bus IO Address [ x2A ]
Bus Memory Address [ xE ]
Define device only, do not configure yes
F1=Help F2=Refresh F3=Cancel F4=List
F5=Reset F6=Command F7=Edit F8=Image
F9=Shell F1 =Exit Enter=Do
Figure 39. SMIT Configuration Menu for Adding an X.25 Interface Co-Processor ISA
Adapter
This configuration menu also provides the capability to select the Define
device only, do not configure option to have the adapter defined but not
configured. Change this field value to yes. It will allow you to define the
adapter without configuring it. If any parameter conflicts were detected, an error
message similar to the following is displayed:
ampx1 Defined
lsresource : The attribute(s) for some device(s) in the system
could not be resolved.
To resolve conflicts, attribute(s) need to be
modified. A suggested value for each attribute is provided.
DEVICE ATTRIBUTE CURRENT SUGGESTED DESCRIPTION
--------------- --------------- --------- --------- -----------
ampx1
bus_intr_lvl 11 9 Interrupt Level
ampx1 bus_io_addr x2a xaa Connection Address
ampx1 Deleted
Change the parameter value as suggested by the lsresource command, and
press Enter.
13. Once no parameters conflicts are reported, you can set the DIP switches on
the adapter card, as described in 6.7.1, “DIP-Switch Setting” on page 121, to
reflect the selected parameters' correct values.
14. Shut down and power-off the system.
124 Introduction to PCI-Based RS/6000 Servers
