Add a Token Ring ISA Adapter
Type or select values in entry fields.
Press Enter AFTER making all desired changes.
[Entry Fields]
Description IBM 16/4 PowerPC Token-Ring
Parent Device bus1
Bus interrupt level [9]
Address of bus memory used for BIOS [ xcc ]
Bus I/O address [ xa2 ]
Bus memory address [ xd ]
Width of shared bus memory [64k]
RING speed [16]
Receive ATTENTION MAC frame no
Receive BEACON MAC frame no
Enable ALTERNATE TOKEN RING address no
ALTERNATE TOKEN RING address [ x]
Define device only, do not configure yes
F1=Help F2=Refresh F3=Cancel F4=List
F5=Reset F6=Command F7=Edit F8=Image
F9=Shell F1 =Exit Enter=Do
Figure 41. SMIT Configuration Menu for Adding an Auto 16/4 Token-Ring ISA Adapter
This configuration menu also provides the capability to select the Define
device only, do not configure option to have the adapter defined but not
configured. Change this field value to yes. It will allow you to define the
adapter without configuring it. If any parameter conflicts were detected, an
error message similar to the following is displayed:
tok1 Defined
lsresource : The attribute(s) for some device(s) in the system
could not be resolved.
To resolve conflicts, attribute(s) need to be
modified. A suggested value for each attribute is provided.
DEVICE ATTRIBUTE CURRENT SUGGESTED DESCRIPTION
--------------- --------------- --------- --------- -----------
tok1
bios_addr Xcc xd8 ROM memory address
tok1 bus_io_addr xa2 xa24 Bus I/O Address
tok1 shared_mem_addr xd xc Bus Memory Address
tok1 Deleted
Change the parameter value as suggested by the lsresource command, and
press Enter.
Note: Instead of using the SMIT menu, you may use the following command
to select the previously set and tested parameters:
mkdev -c adapter -s isa -t tokenring -a intr_lvl=IRQ \
-a bus_io_addr=IO -a shared_mem_addr=MEM \
-a shared_mem_length=LEN -a bios_addr=BIOS
-a ring_speed=SPEED -p bus1
where:
