Notes:
Refer to the document
Adapters, Devices, and Cable Information for Multi
Bus Systems, SA38-0516-00, for detailed information on DIP-switch
positions for setting other parameter values.
The
on and off DIP-switch selections are set by switching them down and
up, respectively. The mapping is:
off = up
on = down
a
This switch is factory set to indicate the size of RAM installed on the
adapter. Verify that the position of this switch is
off to reflect a RAM size of
1 MB.
b
Indicates whether a one-edge (62-pin) or a two-edge (62-pin and
36-pin) connector is used to hold your adapter.
on = two-edged / off = one-edged
c
Sets the bus width and should generally be set to 8-bit.
on = 8-bit / off = 16-bit
Table 22. 4-Port Multiprotocol Adapter: DIP-Switch Suggested Settings
Dip
Switch
#
Position
Comment
First
Adapter
Second
Adapter
Third
Adapter
1
on
off
on
IRQ Level
First Card: 7
Second Card: 9
Third Card: 10
2
off
off
on
3
on
on
off
4
off
off
off
Memory Size
a
5
off
off
off
I/O Port Address
First Card: 06A0
Second Card: 0EA0
Third Card: 016A0
6
on
off
on
7
on
on
off
8
on
on
on
9
on
on
on
Edge Connector
b
10
off
off
off
Bus-Width
c
6.6.3 Configuring the Adapter
The following procedures apply to every PCI-based RS/6000 system that support
the 4-Port Multi-Protocol ISA Adapter.
The configuration for this adapter requires you to specify the
Interrupt Level, the
Bus I/O Address and the Bus Memory Address to be used with the adapter.
1. Check if there are any ISA adapters that are already installed in your computer
by using the following command:
lsdev -Cc adapter -s isa
