Page 11
–9–
• PURY-P400·500YMF-C
2
2
2
2
2
COMPONENT OF EQUIPMENT
[1] Appearance of Components
Outdoor unit
Propeller fan
Heat exchanger(front)
Compressor
Propeller fan
Fan motor
Fan motor
Heat exchanger(rear)
SV block 1
SV block 2
4–way
valve
4–way valve
CS circuit
Drier
CV
block 1
CV block 2
Control box
Compressor
Compressor
P500 TYPE
P400 TYPE
Accumulator
