Scsi backplane components – Gateway ALR 7200 User Manual
Page 37
Components 25
SCSI backplane components
The SCSI backplane connects the SCA-2 LVD SCSI drives to the SCSI
RAID controller or the SCSI controllers on the system board. The
backplane provides automatic SCSI address setting and allows
hot-swapping of SCSI drives. Figure 10 shows the back of the backplane
where the drives connect.
Figure 10: The Back of the SCSI Backplane
To configure the quick hot-swap backplane, see the Quick Hot-swap
Installation Guide that was shipped with the system.
4077.boo Page 25 Thursday, January 21, 1999 9:48 AM
