16 Maintaining and Troubleshooting the Gateway ALR 7200 Server
AI Mouse/keyboard ports
AJ Serial port 2
AK Parallel port
AL Serial port 1
AM CPU connector 1
AN CPU connector 2
AO DIMM bank A
AP DIMM bank B
AQ DIMM bank C
AR DIMM bank D
AS CPU fan 1 connector
AT Embedded VRM for CPU 1
AU Socket for optional VRM for CPU 2
AV CPU fan 2 connector
AW CPU speed setting jumpers
AX RAID cage connector
AY LED display switch connector
AZ SHM mode jumper
Chassis fans
There are several chassis fan connectors on the system board. These
connectors provide power for cooling fans that may be positioned in several
parts of the chassis to provide cooling for critical components.
Power connectors
There are several power connectors that provide power for the system
board. Some of these connectors provide power for specialized functions.
Primary power connectors
The primary power connectors provide the majority of the power to the
system board. These connectors are designed to accommodate the power
supply installed in the system.
