Components 19
HDD LED connector
This connector allows you to connect all of the hard drives to the hard drive
activity connector on the front cover. This connector is not used in this
system.
EDC reset connector
The EDC reset connector provides the connection for the keyboard lock
button/ECC reset button from the front cover. This connector is not used in
this system.
Speaker connector
Connects the internal speaker to the system board.
External boot ROM connector
Provides connection for expansion cards that contain a separate boot ROM
and require separate access to the system board.
LED display switch connector
Connects the LEDs and switches on the front cover to the system board.
Server management connectors
The server management connectors provide hardware and component
monitoring to assist you in maintaining the server.
Server management connector
The server management connector allows you to connect a server
management device to the system board to monitor system activities.
