- DIN Controllers & Indicators - Product Manual
P6700, P8700 & P4700 Limit Controllers – Setup Mode
This mode is normally selected only after Configuration Mode has been completed, and is
used when a change to the process set up is required.
Note:
Scrolling through Parameters & Values
Press to scroll through the parameters (refer to the table below) and their values.
Changing Parameter Values
the required parameter, then pr to set the value as
required.
Once the displayed value is changed, the effect is immediate. No confirmation of the
change is required.
Table 22. P6700, P8700 & P4700 Set Up Mode Parameters
Parameter
Entry into Setup Mode is security-protected by the Setup Mode lock code.
Entry into the Setup Mode
Hold down and press to enter the Select Mode
Press or to navigate to the Setup Mode option, then press to enter
Setup Mode.
The Setup LED will light while in Setup mode
Press to select ess or
Note:
If there is no key activity for two minutes, the instrument returns to the operator mode.
Lower
Display
Upper Display
Adjustment Range
Default
Value
When
Visible
Limit Setpoint value -) Scaled Range Minimum to
Scaled Range Maximum Range
max when
3/+'=$
Range min
when
3/+'='
Always
$5-/ 1 LSD to full span in
display units, on the safe
side of the limit SP
"'/ OFF, 0.5 to 100.0 secs in
0.5 sec increments
(see
CAUTION note at
end of section)
Limit Hysteresis Always
Input Filter Time
constant . Always
