7 Instrument Operation Modes
All instruments in the range share a similar user interface. Indicator models (single 4-digit
display) the legend shown in the “Lower Display” column will be shown for approx 1 second
before the “Upper Display” value is shown. For more details, refer to the mode tables below.
Table 5. Model Groups
Model Group Description Model Group Description
P6100, P6120,
P8100 & P4100 Process
Controllers P6170, P8170 &
P4170 Valve Motor
Controllers
P6010 & P8010 Indicators P4700, P6700 &,
P8700 Limit Controllers
Select Mode
This mode is used to gain entry to each of the modes available in the instrument.
Entry into the Select Mode
Hold down and press in any mode to force the unit to enter Select Mode.
Navigating in Select Mode
Once in Select Mode, press or to select the required mode,
then press to enter the chosen mode.
To prevent unauthorised entry to Configuration, Setup and Automatic Tuning modes, an
unlock code is required. These are shown in the - Lock code values table.
Table 6. Select Mode Menus
Mode Description Upper/Main
Display
Lower
Display (or
1 st Legend)*
1 /
8
DIN
Indicator
Units Display
Operator
Mode The Default Mode on power up
used for normal operation.
@/+ -'3/ -
Set Up Mode Used to tailor the instrument to
the application, adjustment of
tuning terms etc.
-!/@ -'3/ -
Configuration
Mode Used to configure the
instrument for first time use or
on re-installation.
3 C" -'3/ -
Product
Information
Mode Used to check the hardware,
firmware and manufacturing
information of the instrument.
C" -'3/ -
Automatic
Tune Mode Used to invoke pre-tune or
self-tune on controllers
/1C -'3/ -
*Note:
On Indicators, this legend is shown for approx 1 second before the Main display value.
