Option Slot 3 - Dual Relay Output Module
If option slot 3 is fitted with a dual relay output module, make connections as illustrated. This
module has two independent relays, which share a common connection terminal. The
contacts are rated at 2 amp resistive 240 VAC. (120V max for direct Valve Motor control).
Option Slot 3 Dual
Relay is not available
on 1 /
16
DIN models
10
N/O OUTPUT 3
12
N/O OUTPUT 5
11
COMMON
1 /
16
DIN 1 /
4
DIN & 1 /
8
DIN
Figure 30. Option Slot 3 - Dual Relay Module
WARNING:
THIS MODULE MUST NOT BE FITTED INTO OPTION SLOT 3 ON 1 /
16
DIN INSTRUMENTS.
Option Slot 3 - Transmitter Power Supply Module
If option slot 3 is fitted with a transmitter power supply module, make connections as
illustrated. The output is an unregulated 24V DC, 22mA supply.
16
17
_
18
+
10
11
_
12
+
1 /
16
DIN 1 /
4
DIN & 1 /
8
DIN
Figure 31. Option Slot 3 - Transmitter Power Supply Module
WARNING:
THIS MODULE MUST NOT BE FITTED INTO OPTION SLOT 2.
