- DIN Controllers & Indicators - Product Manual
Parameter ASCII Ident &
Message Types
Notes Modbus
Parameter No.
Serial Number Low 123 RO Digits aaaa
Serial Number Mid 124 RO Digits bbbb
Serial Number High 125 RO Digits cccc
Unit serial number.
Format aaaa bbbb
cccc, (12 BCD digits).
Date of
manufacture 126 RO Manufacturing date code as an
encoded binary number.
E.g. 0403 for April 2003 is returned as
193hex
Low Byte Alpha part of PRL.
E.g. A = 01hex Product Revision
Level 129 RO
High Byte Numeric part of PRL.
E.g. 13 = 0Dhex
Bits Meaning
0 - 4 Revision number (1,2...)
5 - 9 Alpha version (A=0,
B=1...)
Firmware Version 130 RO
Numeric version
(starting from 121 = 0) 10 - 15
Input status 133 RO Input status. Read Only.
Bit 0: Sensor break flag
Bit 1: Under-range flag
Bit 2: Over-range flag
Tare Enable 2111 R/W 0 = Disabled, 1 = Enabled
Tare Activate 2112 RO Write any value to activate.
2214 R/W Option Slot 1
Re-transmit output
Maximum Maximum scale value for retransmit
output in slot 1, 1999 to 9999.
Option Slot 1
Re-transmit output
Minimum 2215 R/W Minimum scale value for retransmit
output in slot 1, 1999 to 9999.
Option Slot 2
Re-transmit output
Maximum 2224 R/W Maximum scale value for retransmit
output in slot 2, 1999 to 9999.
Option Slot 2
Re-transmit output
Minimum 2225 R/W Minimum scale value for retransmit
output in slot 2, 1999 to 9999.
Option Slot 3
Re-transmit output
Maximum 2234 R/W Maximum scale value for retransmit
output in slot 3, 1999 to 9999.
Option Slot 3
Re-transmit output
Minimum 2235 R/W Minimum scale value for retransmit
output in slot 3, 1999 to 9999.
Note:
Some of the parameters that do not apply to a particular configuration will accept reads
and writes (e.g. attempting to scale a Linear output which has not been fitted). Read only
parameters will return an exception if an attempt is made to write values to them.
59305, Issue 6 – March 2006
P6010 & P8010 Model Group Page 117
