- DIN Controllers & Indicators - Product Manual
Parameter Modbus
Parameter No.
ASCII Ident &
Message Types
Notes
Serial Number Low 123 RO Digits aaaa
Serial Number Mid 124 RO Digits bbbb
Serial Number High 125 RO Digits cccc
Unit serial number.
Format aaaa bbbb
cccc, (12 BCD digits).
Date of
manufacture 126 RO Manufacturing date code as an
encoded binary number. (e.g. 0403 for
April 2003 is returned as 193hex)
Product Revision
Level 129 RO Bits 0 – 7: Alpha part of PRL. (e.g. A =
01hex)
Bits 8 – 15: Numeric part of PRL. (e.g.
13 = 0Dhex)
Firmware Version 130 RO Bits 0 – 4: Revision number (1,2...)
Bits 5 – 9: Alpha version (A=0, B=1...)
Bits 10 – 15: Numeric version (starting
from 121 = 0)
Input status 133 RO Input status. Read Only.
Bit 0: Sensor break flag
Bit 1: Under-range flag
Bit 2: Over-range flag
Remote Setpoint
Lower Limit 2123 R/W Y
Type 2, 3/4 R/W
RSP value to be used when RSP
input is at minimum. -1999 to 9999
Remote Setpoint
Upper Limit 2124 R/W X
Type 2, 3/4 R/W
RSP value to be used when RSP
input is at minimum. -1999 to 9999
Option Slot 1
Re-transmit output
Maximum 2214 R/W Maximum scale value for retransmit
output in slot 1, -1999 to 9999.
Option Slot 1
Re-transmit output
Minimum 2215 R/W Minimum scale value for retransmit
output in slot 1, -1999 to 9999.
Option Slot 2
Re-transmit output
Maximum 2224 R/W Maximum scale value for retransmit
output in slot 2, -1999 to 9999.
Option Slot 2
Re-transmit output
Minimum 2225 R/W Minimum scale value for retransmit
output in slot 2, -1999 to 9999.
Option Slot 3
Re-transmit output
Maximum 2234 R/W Maximum scale value for retransmit
output in slot 3, -1999 to 9999.
Option Slot 3
Re-transmit output
Minimum 2235 R/W Minimum scale value for retransmit
output in slot 3, -1999 to 9999.
Note:
Some of the parameters that do not apply for a particular configuration will accept reads
and writes (e.g. attempting to scale a Linear output which has not been fitted). Read only
parameters will return an exception if an attempt is made to write values to them.
