Pyromation Series 610 1_16 DIN - Manual (Page 102)

1 /
4
-DIN, 1 /
8
-DIN & 1 /
16
- DIN Controllers & Indicators - Product Manual
Parameter Modbus
Parameter No.
ASCII Ident &
Message Types
Notes
123 RO Serial Number Low Digits aaaa
Serial Number Mid 124 RO Digits bbbb
Unit serial number.
Format aaaa bbbb
cccc, (12 BCD digits).
Serial Number High 125 RO Digits cccc
Date of
manufacture 126 RO Manufacturing date code as an
encoded binary number.
E.g. 0403 for April 2003 is returned as
193hex
Low Byte Alpha part of PRL.
E.g. A = 01hex 129 RO
High Byte
Meaning
0 - 4 Revision number (1,2...)
5 - 9 Alpha version (A=0,
B=1...)
Firmware Version 130 RO
10 - 15 Numeric version
(starting from 121 = 0)
Input status 133 RO Input status. Read Only.
Bit 0: Sensor break flag
Bit 1: Under-range flag
Bit 2: Over-range flag
Option Slot 2
Re-transmit output
Maximum 2224 R/W Maximum scale value for retransmit
output in slot 2, 1999 to 9999.
Option Slot 2
Re-transmit output
Minimum 2225 R/W Minimum scale value for retransmit
output in slot 2, 1999 to 9999.
Option Slot 3
Re-transmit output
Maximum 2234 R/W Maximum scale value for retransmit
output in slot 3, 1999 to 9999.
Option Slot 3
Re-transmit output
Minimum 2235 R/W Minimum scale value for retransmit
output in slot 3, 1999 to 9999.
Product Revision
Level
Numeric part of PRL.
E.g. 13 = 0Dhex
Bits
Note:
Some of the parameters that do not apply to a particular configuration will accept reads
and writes (e.g. attempting to scale a Linear output which has not been fitted). Read only
parameters will return an exception if an attempt is made to write values to them.
59305, Issue 6 – March 2006
P6700, P8700 & P4700 Model Group Page 97
