Option Slot 2 - Dual Relay Output Module
If option slot 2 is fitted with a dual relay output module, make connections as illustrated. This
module has two independent relays, which share a common connection terminal. The
contacts are rated at 2 amp resistive 240 VAC. (120V max for direct Valve Motor control).
22
23
N/O OUTPUT 4
COMMON
24
N/O OUTPUT 2
13
14
N/O OUTPUT 2
COMMON
15
N/O OUTPUT 4
1 /
16
DIN 1 /
4
DIN & 1 /
8
DIN
Figure 25. Option Slot 2 - Dual Relay Module
WARNING:
THIS MODULE MUST NOT BE FITTED INTO OPTION SLOT 3 ON 1 /
16
DIN INSTRUMENTS.
Option Slot 2 - Linear Voltage or mADC Output module
If option slot 2 is fitted with a DC linear output module, make connections as illustrated.
22
23
_
24
+
13
14
+
15 _
1 /
16
DIN 1 /
4
DIN & 1 /
8
DIN
Figure 26. Option Slot 2 - Linear Voltage & mADC module
