- DIN Controllers & Indicators - Product Manual
Thermocouple Performance
Calibration: Complies with BS4937, NBS125 and IEC584.
Measurement
Accuracy: ±0.1% of full range span ±1LSD.
NOTE: Reduced performance for B Thermocouple from 100 to 600°C.
NOTE: PtRh 20% vs PtRh 40% Thermocouple accuracy is 0.25% and has
reduced performance below 800°C.
Linearisation
Accuracy: Better than ±0.2°C any point, for 0.1° resolution ranges (±0.05°C typical).
Better than ±0.5°C any point, for 1° resolution ranges.
Cold Junction
Compensation: Better than ±0.7°C under reference conditions.
Better than ±1°C under operating conditions.
Temperature
Stability: 0.01% of span/ °C change in ambient temperature.
Supply Voltage
Influence: Negligible.
Relative Humidity
Influence: Negligible.
Sensor Resistance
Influence: Thermocouple 100Ω: <0.1% of span error.
Thermocouple 1000Ω: <0.5% of span error.
Sensor Break
Protection: Break detected within two seconds. Process Control outputs turn OFF
(0% power); Valve Control “Close” outputs turn on; Limit outputs turn off
(goes into Exceed condition); Alarms operate as if the process variable is
over-range.
Resistance Temperature Detector (RTD)
RTD Ranges Available
Range Min
in
°C
Range Max
in
°C
Range Min
in
°F
Range Max
in
°F
Resolution
-128.8 537.7 -199.9 999.9 0.1°
-199 800 -328 1472 1°
(default)
Note:
Scale Range Upper Limit and Scale Range Lower Limit Configuration Mode parameters
can be used to restrict range.
Page 162
Specifications 59305, Issue 6 – March 2006
