RIGOL Chapter 2 Front Panel Operations
2-32 DG1000Z User’s Guide
8 bits binary data is used to represent the output status of the 8 orders of
harmonics respectively, wherein, 1 represents enabling the output of the
corresponding harmonic and 0 represents disabling the output of the
corresponding harmonic. Users only need to use the numeric keyboard to
modify the value of each data bit (note: the leftmost bit representing
fundamental waveform is always X and can not be modified). For example, set
the 8 bits data to X001 0001, thus fundamental waveform and 4th and 8th
orders of harmonics are output.
Note: the actual harmonics output is determined by the harmonic order and
harmonic type currently specified.
To Set Harmonic Amplitude
After entering the harmonic setting menu, press Harmonic Ampl to set the
amplitude of each order of harmonic.
1) SN: press this softkey to select the sequence number of the harmonic to be set.
2) Harmonic Ampl: press this softkey to set the amplitude of the harmonic
selected. Use the numeric keyboard to input the amplitude value and then select
the desired unit from the pop-up menu. The units available are Vpp, mVpp,
Vrms, mVrms and dBm (invalid in HighZ).
To Set Harmonic Phase
After entering the harmonic setting menu, press Harmonic Phase to set the phase
of each order of harmonic.。
1. SN: press this softkey to select the sequence number of the harmonic to be set.
2. Harmonic Phase: press this softkey to set the phase of the harmonic selected.
Use the numeric keyboard or the direction keys and knob to input the phase
value and then select the unit “°” from the pop-up menu.
